Global Partitions Bottom Hinge for Surface Mount
Description
Global Partitions Bottom Hinge For Surface Mount. Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/2" wide. The hole spacing is 1-1/2" on center. The lug projects out 1-9/16" and is 1/2" thick. The bushing on the lug is 5/16" diameter. Manufacture part # 3010, 111710. Also used with Flush Metal and General Partitions. Shipped with mounting screws. A=1-9/16". Also used with Accurate Partition doors after January 2013.
Global Partitions Bottom Hinge For Surface Mount. Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/2" wide. The hole spacing is 1-1/2" on center. The lug projects out 1-9/16" and is 1/2" thick. The bushing on the lug is 5/16" diameter. Manufacture part # 3010, 111710. Also used with Flush Metal and General Partitions. Shipped with mounting screws. A=1-9/16"
| Part # | 9G0201 |
|---|---|
| Availability | In Stock |
| Manufacturer | Accurate Toilet Partition, Global Toilet Partition |
| Description | Global Partitions Bottom Hinge For Surface Mount. Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/2" wide. The hole spacing is 1-1/2" on center. The lug projects out 1-9/16" and is 1/2" thick. The bushing on the lug is 5/16" diameter. Manufacture part # 3010, 111710. Also used with Flush Metal and General Partitions. Shipped with mounting screws. A=1-9/16". Also used with Accurate Partition doors after January 2013. |
| Detailed Description | Global Partitions Bottom Hinge For Surface Mount. Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/2" wide. The hole spacing is 1-1/2" on center. The lug projects out 1-9/16" and is 1/2" thick. The bushing on the lug is 5/16" diameter. Manufacture part # 3010, 111710. Also used with Flush Metal and General Partitions. Shipped with mounting screws. A=1-9/16" |
